The nHT series diffusion pumps have been designed for optimum heat transfer to the oil, resulting in faster heat-up times and a significant reduction in energy consumption. In addition, the use of the Energy Efficiency Controller (EEC) provides further reduction in power consumption – up to 30% without the loss of pumping performance.

Features & Benefits

• Optimised pumping speed and high throughput with good stability between 10-2 and 10-3 mbar – critical for many applications.

• Significant energy savings through innovative heating design providing faster warm-up time. When used with the Energy Efficiency Controller a further energy saving can be achieved – up to 30%.

• Smart temperature control and on-board sensors as standard ensure minimum load with a longer lifetime for heaters and oil. Increased productivity through long maintenance intervals with non-wearing components and easy-to-change heater cartridges

• Available in both ANSI and ISO flange options with voltage variants to cover global requirements. A broad range of accessories is available.

• The Energy Efficiency Controller enables ease of use and operating convenience along with effective monitoring with USB and Ethernet interface


Download nHT Diffusion
